See through engine

See through engine

a see through internal combustion engine, see the explosions inside the cylinder

Engine Head

Engine Head

The engine head with tappets, spark plug, valves, and exhaust.

the front of the engine showing the crankshaft, conrod, and piston

the front of the engine showing the crankshaft, conrod, and piston

_DSC0055 (2).JPG

Spark

Spark

A very small bolt of lightning!

see through internal combustion engine

see through internal combustion engine

Internal combustion!

A very rich fuel/air mixture resulting in a yellow flame

A very rich fuel/air mixture resulting in a yellow flame

‘Tân Glas’ is Welsh for ‘Blue Fire’

‘Tân Glas’ is Welsh for ‘Blue Fire’
